Price range: £10.00 through £35.00

Product Description

Upgrade your containment projects with our next-generation 100mm Medium-Duty Cable Tray. Engineered specifically to reduce installation headaches and maximize structural integrity, this 3-metre length features a revolutionary integrated Male-Female S-Joint system. By eliminating the need for traditional, separate couplers and a mountain of nuts and bolts, this tray drastically slashes on-site labour time while delivering a cleaner, significantly stronger finish.

Perfect for commercial data centers, industrial complexes, and high-end residential electrical installations, this 100mm width is the ultimate “workhorse” size for routing power, data, and security cabling safely.

Despite its premium engineering upgrades, this system is priced comparably to traditional options—giving contractors a massive drop in total “installed project cost” without raising material budgets.

SKU: N/A Category: Brand:

Description

Technical Features

  • Integrated Male-Female S-Joint: No more purchasing, organizing, or losing separate couplers on-site. The ends of the tray are precision-engineered to slide directly into one another. The joint locks securely in seconds, cutting assembly time by up to 50%.

  • Structural S-Shape Side Walls: Moving away from standard, flimsy 90-degree edges, our unique “S” profile side wall acts as a structural beam. This significantly increases the tray’s section modulus and load capacity, allowing for increased support spans and requiring fewer overhead brackets across the run.

  • 2mm Dented Safety Perforations: The punching process on traditional trays leaves sharp, raw edges. Our holes feature a 2mm raised, smooth dented radius. This completely prevents cables from contacting sharp metal, protecting delicate insulation during high-tension cable pulls.

  • Advanced Heat Dissipation: The 2mm dented profile creates a natural “stand-off” buffer between the cable and the tray bed. This engineered gap promotes superior airflow and higher heat transfer, helping to maintain optimal current-carrying capacity for power cables.

  • High-Security Cover Locking: The S-shape wall doubles as a high-integrity locking channel. When paired with our matching dented covers, they snap firmly into place, offering rigid protection against mechanical impacts and ensuring a rattle-free finish in high-vibration or outdoor environments.

  • Premium Corrosion Protection: Manufactured from high-quality, corrosion-resistant pre-galvanised steel, designed to withstand standard indoor moisture and sheltered outdoor applications.

Technical Specifications

  • Width: 100mm (10cm)

  • Length: 3 Metres (3000mm)

  • Side Height: 25mm (Medium Duty Profile)

  • Material: Pre-Galvanised Mild Steel

  • Joint Type: Integrated Boltless S-Joint (Male/Female)

  • Perforation Style: 2mm Raised Safety Dents

  • Fixings Required: Zero (For standard straight runs)

Additional information

Width

100, 200, 300
